FAST-CAL: Industrial Temperature Calibrators

Three Models -35°C to 650°C. Volume 25 x 148mm

Feature Video

Using the Fast-Cal Complete: Thermostat Testing

FAST-CAL: Industrial Temperature Calibrators

Three Models -35°C to 650°C. Volume 25 x 148mm

Enquire Here -or- Call us now +44(0)1704 543830

Fast-Cal - the product range you designed !

During early 2004 20 experienced engineers from many parts of the world were asked to produce their ideal specification for industrial calibration. Their top ten requirements, in order of priority, are: Rugged, Lightweight, Easy to use on site, Low cost/high benefit ratio, Fast response, high stability, Time saving features, Multiple sensor testing, Software, Modern design, Compliant with the latest regulations.

One model is ideal for the validation of Washer Disinfectors, Steam Sterilisers and Autoclaves. In place of a removable insert it has a fixed block with pockets for a reference probe and the type of test sensor commonly used in validation applications.

Model HTM 2010 Low Medium High
Range at 20°C -35 to 140°C (1) -35 to 140°C 30 to 350°C 35 to 650°C
Stability 0.02°C 0.02°C 0.03°C 0.03 to 0.05°C
Accuracy - basic ±0.2°C ±0.02°C ±0.3°C ±1°C (500°C) ±2°C (650°C)
Accuracy - complete (2) ±0.15°C ±0.15°C ±0.2°C ±0.5°C
Heating Time -30 to +140°C in 15 minutes -30 to +140°C in 15 minutes 50 to 350°C in 15 minutes 50 to 650°C in 15 minutes
Cooling Time +140 to 0°C in 15 minutes +140 to 0°C in 15 minutes 350 to 100°C in 40 minutes 650 to 300°C in 20 minutes
Calibration Capacity 145mm depth 8Ø, 6.5Ø, 3 x 4.5Ø 148mm depth 25mmØ 148mm depth 25mm Ø 148mm depth 25mm Ø
Power 150W 150W 750W 750W
Traceable Certificate Included Included Included Included
UKAS Certificate Extra Extra Extra Extra
PC Communications Included Included Included Included
Software Indluded Included Included Included
4-20mA Input Complete Models Complete Models Complete Models Complete Models
Ramps and Dwells Yes with Software Yes with Software Yes with Software Yes with Software
Dimensions 228 x 248 x 143mm 228 x 248 x 143mm 228 x 248 x 143mm 228 x 248 x 143mm
Weight 6.60kg 6.60kg 6.35kg 6.35kg








×
